ALIGN T-REX 700N Autorotation Tail Drive Gear M1 104T
|
Suitable for T-REX 700E, 700L, 700X, 700N, 700XN, 760X, 800E RC Helicopter Electric / Nitro Series Must Use Torque Tube Front Drive Gear M1 22T - H70G001BXW |
Specifications Teeth Count: 104T Gear: Slant / Helical Gear Ratio 1:4.95 Package Includes 700N Autorotation Tail Drive Gear M1-104T x 1 |
| T-REX 700 Tail Drive Gear Ratio with Main Rotor Head Speed Table |
| Main Blades | Tail Blade | RPM approx. | Tail Drive Gear | Front Drive Gear | Drive Gear Ratio |
| 700 | 106 | 2150 ~ 2200 RPM | 102T | H70G001NXW 23T M1 Red HE1G005XXW 19T M1.25 Blue |
8.46/1/4.43 |
| 700 | 106 | 2000 ~ 2150 RPM | 104T | H70G001BXW 22T Red | 8.46/1/4.73 |
| 700 | 106 | < 2000 RPM | 105T | H70G013XXW 20T Red | 8.46/1/5.25 |
| For your safety, DO NOT exceed 2200 RPM or increase RPM beyond the chart's recommendations for Tail Gearing, as this may result in damage to the helicopter, the property of others, yourself, or others | |||||
ALIGN T-REX 700N Autorotation Tail Drive Helical Gear M1-104T H70G007XXW
- Brand ALIGN
- Product Code: 01-H70G007XXW
- Availability: Out Of Stock
-
$21.99
