This is the MKS DS95i Titanium Gear High Speed Digital Micro Helicopter Tail Servo. With features that include a chrome/titanium alloy gear train, an aluminum center case, as well as an aluminum upper and lower case, this servo is practically bomb proof. Plus with its Super Narrow Pulse 760μs with AVCS, .03 transit speed and 33 oz/in of torque @ 6 volts, the DS95-i provides impressive reaction, speed and torque that makes it an excellent tail servo.

Product Information

For 300, 450, 470 Class RC Helicopters

Recommended Use: RC Helicopter - Tail

High Speed Response

Band: Narrow

Case: All Aluminum

Gears: Metal Alloy

Motor: Japanese Coreless

Specifications

  • Dead Band: 0.0005ms (Default)
  • Control System: +Pulse Width Control
  • Working Frequency: 760μs / 560hz
  • Operating Voltage: 4.8 ~ 7.0 Volts
  • Operating Temperature Range: -10 to + 60 Degree C
  • Operating Speed:
    • @4.8V: 0.047 sec/60° degrees at no load
    • @6.0V: 0.038 sec/60° degrees at no load
  • Stall Torque:
    • @4.8V: 26.7 oz-in (1.92 kg/cm)
    • @6.0V: 33.3 oz-in (2.40 kg/cm)
  • 360° Modifiable: NO
  • Motor Type: Coreless Motor
  • Potentiometer Drive: Direct Drive
  • Bearing Type: Dual Ball Bearings
  • Gear Type: Metal Gears
  • Dimensions: 23x12x27.25mm
  • Weight: 21.21g (0.75oz)

Write a review

Please login or register to review

MKS DS95i Brushless High Speed Digital Tail Servo MKS-DS95I

  • Brand MKS
  • Product Code: 52-MKS-DS95I
  • Availability: In Stock
  • $85.50
